Model NO. | DTCM230-258-AL | Image Circle Diameter (Φmm) | 11.4(2/3") | ||||
Magnification(x) | 0.044 | Working Distance(mm) | 338±5 | ||||
NA | 0.0045 | Type | Bi-Telecentric | ||||
Mount | C | Object Field of View(Φmm) | 258 | ||||
Best Aperture(f/#) | 4.9 | MTF30 (lp/mm) | >180 | ||||
Depth of Field(mm) | ±225@F11 | Distortion Typical(% max) | <0.1 | ||||
Telecentricity Typical (°max) | <0.1 | Length of I/O(mm) | 785±5 | ||||
Length (mm) | 429.9 | Weight(kg) | 24.3 | ||||
Measured Depth of Field (mm) | 31 | Filter Screw Size | M285x1.0 | ||||
Field of View (mm × mm) |
1/1.8" EV76C570 (7.2x5.4) | 163.6x122.7 | |||||
1/1.7" IMX226 (7.5x5.6) | 170.5x127.3 | ||||||
2/3" IMX250/264 (8.45x7.1) | 192.0x161.4 | ||||||
Compatible Lighting | Telecentric LED Lighting | LP270-90 | |||||
