Model NO. |
WWK066-110C-110 |
Image Circle Diameter (Φmm) |
16(1") |
Magnification(x) |
0.66 |
Working Distance(mm) |
110±2 |
NA |
0.0471 |
Type |
Telecentric |
Mount |
C |
Best Aperture(f/#) |
7 |
MTF30 (lp/mm) |
>135 |
Object Resolution(μm) |
7.1 |
Depth of Field(mm) |
±0.6@F7 |
Distortion Typical(% max) |
<0.02 |
Telecentricity Typical (°max) |
<0.01 |
Length (mm) |
129.8 |
With Coaxial Illumination Port |
Yes |
Measured Depth of Field (mm) |
0.6 |
Filter Screw Size |
M42x0.5 |
Field of View (mm x mm) |
1/1.8" EV76C570 (7.2x5.4) |
18.8x14.9 |
1/1.7" IMX226 (7.5x5.6) |
21.5x11.4 |
2/3" IMX250/264 (8.45x7.1) |
19.9x13.3 |
Dimensions
![]()
Naming Rule
![]()
