How to customize a calibration target?

How to customize
a calibration target?

Contact Us

1: Select the substrate material.

2: Select the manufacturing proces.

3: Send the drawing / OKLAB help to design.

Quotation

1: Receive OKLAB's quotation.

Confirm

1: Sign order.

2: Double confirm the manufacturing drawing.

Express

1: Generally, customization manufacturing time is within 7 working days after the drawings are confirmed.

2: Wait for express package.

How to select the substrate material?

How to select the manufacturing process?

Minimum Line/Spce
(Required Accuracy)
≥0.7μm (±1μm) Laser Writing-Chrome Bright Chrome (High Reflective)
Brown Chrome (Usual)
Blue Chrome
(Low Reflective, OD>4.5)
≥20μm (±2μm) Laser Writing-Black Coating Non Reflective, OD>5
Carbon Fiber,
≥15μm (±10μm) Laser Drawing-Silver Bromide 100% Black OD>4.5
Gray scale OD are on request.
≥20μm (±2μm) Inkjet-Ink High Contrast
  • Chrome on Soda Lime Glass / Quartz Glass

    Minimum Line/Space: ≥0.7μm (±1μm)

  • Chrome on Matte Ceramic / Glossy Ceramic

    Minimum Line/Space: ≥2μm(±1μm)

  • Black Coating on Glass


    Minimum Line/Space: ≥20μm(±2μm)

  • Film


    Minimum Line/Space: ≥15μm(±10μm)

  • White PE / White Film / Paper

    Minimum Line/Space: ≥0.05mm / 0.3mm / 0.3mm
