1.2” C-Mount Telecentric Lenses



Image Model No. Image Circle Diameter (Φmm) Magnification(x) Working Distance(mm) NA Type Mount Price Buy
  DTCM120-36-AL 8(1/2") 0.277 110±2 0.0264 Bi-Telecentric C $876.00
  DTCM120-42-AL 8(1/2") 0.190 118±3 0.0227 Bi-Telecentric C $935.00
  DTCM120-48-AL 8(1/2") 0.167 128±3 0.0198 Bi-Telecentric C $1,071.00
  DTCM120-48S-AL 8(1/2") 0.167 138±3 0.0198 Bi-Telecentric C $1,071.00
  DTCM120-56-AL 8(1/2") 0.143 138±3 0.0170 Bi-Telecentric C $1,169.00
  DTCM120-64-AL 8(1/2") 0.125 189±3 0.0133 Bi-Telecentric C $1,266.00
  DTCM120-64H-AL 8(1/2") 0.125 158±3 0.0149 Bi-Telecentric C $1,266.00
  DTCM120-72-AL 8(1/2") 0.111 178±3 0.0132 Bi-Telecentric C $1,805.00
  DTCM120-80H-AL 8(1/2") 0.100 228±4 0.0119 Bi-Telecentric C $2,005.00
  DTCM120-90-AL 8(1/2") 0.089 208±3 0.0106 Bi-Telecentric C $1,949.00
  DTCM120-100H-AL 8(1/2") 0.080 238±4 0.0095 Bi-Telecentric C $2,144.00
  DTCM120-110-AL 8(1/2") 0.073 263±4 0.0087 Bi-Telecentric C $2,444.00
  DTCM120-120H-AL 8(1/2") 0.067 273±5 0.0794 Bi-Telecentric C $2,727.00
  DTCM120-136-AL 8(1/2") 0.059 288±5 0.0070 Bi-Telecentric C $3,215.00
  DTCM120-150-AL 8(1/2") 0.053 300±5 0.0064 Bi-Telecentric C $3,702.00
  DTCM120-170-AL 8(1/2") 0.047 318±5 0.0056 Bi-Telecentric C $5,124.00
  DTCM120-190H-AL 8(1/2") 0.042 330±5 0.0050 Bi-Telecentric C $6,546.00
  DTCM120-216-AL 8(1/2") 0.037 372±5 0.0044 Bi-Telecentric C $9,273.00
  DTCM120-240H-AL 8(1/2") 0.033 410±6 0.0040 Bi-Telecentric C $11,981.00
  DTCM120-258-AL 8(1/2") 0.031 338±5 0.0037 Bi-Telecentric C $13,247.00
  DTCM120-300-AL 8(1/2") 0.027 465±6 0.0032 Bi-Telecentric C $17,591.00
  WWK015-320-120-AL 8(1/2") 0.150 320±2 0.0107 Telecentric C $1,071.00
  WWK012-320-120-AL 8(1/2") 0.120 330±2 0.0086 Telecentric C $1,157.00
  WH012-250A 8(1/2") 0.120 250 0.0050 Fixed Magnification C $386.00
  WH012-300A 8(1/2") 0.120 300 0.0060 Fixed Magnification C $600.00
  WH012-340A 8(1/2") 0.120 340 0.0060 Fixed Magnification C $600.00
  WH012-650A-120 8(1/2") 0.120 650 0.0075 Fixed Magnification C $386.00
  WH015-355A 8(1/2") 0.150 355 0.0100 Fixed Magnification C $386.00
  WH0155-350A-120 8(1/2") 0.155 350 0.0129 Fixed Magnification C $386.00
  WH016-525A-120 8(1/2") 0.160 525 0.0044 Fixed Magnification C $386.00
  WH018-240A-120 8(1/2") 0.180 240 0.0081 Fixed Magnification C $386.00
  WH018-300A-120 8(1/2") 0.180 300 0.0103 Fixed Magnification C $386.00
  WH02-180A-120 8(1/2") 0.200 180 0.0095 Fixed Magnification C $471.00
  WH02-650A-120 8(1/2") 0.200 650 0.0100 Fixed Magnification C $386.00
  WH022-145A 8(1/2") 0.220 145 0.0103 Fixed Magnification C $386.00
  WH022-150A-120 8(1/2") 0.220 150 0.0110 Fixed Magnification C $386.00
  WH022-150A-120IR 8(1/2") 0.220 150 0.0138 Fixed Magnification C $386.00
  WH022-160A-120 8(1/2") 0.220 160 0.0082 Fixed Magnification C $471.00
  ＷＨ025-340A-120 8(1/2") 0.250 340 0.0138 Fixed Magnification C $450.00
  WH027-220A-120 8(1/2") 0.270 220 0.0163 Fixed Magnification C $386.00
  WH03-130A-120 8(1/2") 0.300 130 0.0133 Fixed Magnification C $386.00
  WH03-180A-120 8(1/2") 0.300 180 0.0133 Fixed Magnification C $386.00
  WH03-240A-120 8(1/2") 0.300 240 0.0167 Fixed Magnification C $386.00
  WH03-530-123 8(1/2") 0.300 530 0.0188 Fixed Magnification C $471.00
  WH05-300CT 8(1/2") 0.500 300 0.0100 Fixed Magnification C $557.00
  WH05-330CIR 8(1/2") 0.500 330 0.0210 Fixed Magnification C $557.00
  WH10-250CS-120 8(1/2") 1.000 250 0.0250 Fixed Magnification C $386.00
  WH20-300A-120 8(1/2") 2.000 300 0.0333 Fixed Magnification C $494.00



Image Model No. Image Circle Diameter (Φmm) Magnification(x) Working Distance(mm) NA Type Mount Price Buy
  DTCM120-36-AL 8(1/2") 0.277 110±2 0.0264 Bi-Telecentric C $876.00
  DTCM120-42-AL 8(1/2") 0.190 118±3 0.0227 Bi-Telecentric C $935.00
  DTCM120-48-AL 8(1/2") 0.167 128±3 0.0198 Bi-Telecentric C $1,071.00
  DTCM120-48S-AL 8(1/2") 0.167 138±3 0.0198 Bi-Telecentric C $1,071.00
  DTCM120-56-AL 8(1/2") 0.143 138±3 0.0170 Bi-Telecentric C $1,169.00
  DTCM120-64-AL 8(1/2") 0.125 189±3 0.0133 Bi-Telecentric C $1,266.00
  DTCM120-64H-AL 8(1/2") 0.125 158±3 0.0149 Bi-Telecentric C $1,266.00
  DTCM120-72-AL 8(1/2") 0.111 178±3 0.0132 Bi-Telecentric C $1,805.00
  DTCM120-80H-AL 8(1/2") 0.100 228±4 0.0119 Bi-Telecentric C $2,005.00
  DTCM120-90-AL 8(1/2") 0.089 208±3 0.0106 Bi-Telecentric C $1,949.00
  DTCM120-100H-AL 8(1/2") 0.080 238±4 0.0095 Bi-Telecentric C $2,144.00
  DTCM120-110-AL 8(1/2") 0.073 263±4 0.0087 Bi-Telecentric C $2,444.00
  DTCM120-120H-AL 8(1/2") 0.067 273±5 0.0794 Bi-Telecentric C $2,727.00
  DTCM120-136-AL 8(1/2") 0.059 288±5 0.0070 Bi-Telecentric C $3,215.00
  DTCM120-150-AL 8(1/2") 0.053 300±5 0.0064 Bi-Telecentric C $3,702.00
  DTCM120-170-AL 8(1/2") 0.047 318±5 0.0056 Bi-Telecentric C $5,124.00
  DTCM120-190H-AL 8(1/2") 0.042 330±5 0.0050 Bi-Telecentric C $6,546.00
  DTCM120-216-AL 8(1/2") 0.037 372±5 0.0044 Bi-Telecentric C $9,273.00
  DTCM120-240H-AL 8(1/2") 0.033 410±6 0.0040 Bi-Telecentric C $11,981.00
  DTCM120-258-AL 8(1/2") 0.031 338±5 0.0037 Bi-Telecentric C $13,247.00
  DTCM120-300-AL 8(1/2") 0.027 465±6 0.0032 Bi-Telecentric C $17,591.00
  WWK015-320-120-AL 8(1/2") 0.150 320±2 0.0107 Telecentric C $1,071.00
  WWK012-320-120-AL 8(1/2") 0.120 330±2 0.0086 Telecentric C $1,157.00
  WH012-250A 8(1/2") 0.120 250 0.0050 Fixed Magnification C $386.00
  WH012-300A 8(1/2") 0.120 300 0.0060 Fixed Magnification C $600.00
  WH012-340A 8(1/2") 0.120 340 0.0060 Fixed Magnification C $600.00
  WH012-650A-120 8(1/2") 0.120 650 0.0075 Fixed Magnification C $386.00
  WH015-355A 8(1/2") 0.150 355 0.0100 Fixed Magnification C $386.00
  WH0155-350A-120 8(1/2") 0.155 350 0.0129 Fixed Magnification C $386.00
  WH016-525A-120 8(1/2") 0.160 525 0.0044 Fixed Magnification C $386.00
  WH018-240A-120 8(1/2") 0.180 240 0.0081 Fixed Magnification C $386.00
  WH018-300A-120 8(1/2") 0.180 300 0.0103 Fixed Magnification C $386.00
  WH02-180A-120 8(1/2") 0.200 180 0.0095 Fixed Magnification C $471.00
  WH02-650A-120 8(1/2") 0.200 650 0.0100 Fixed Magnification C $386.00
  WH022-145A 8(1/2") 0.220 145 0.0103 Fixed Magnification C $386.00
  WH022-150A-120 8(1/2") 0.220 150 0.0110 Fixed Magnification C $386.00
  WH022-150A-120IR 8(1/2") 0.220 150 0.0138 Fixed Magnification C $386.00
  WH022-160A-120 8(1/2") 0.220 160 0.0082 Fixed Magnification C $471.00
  ＷＨ025-340A-120 8(1/2") 0.250 340 0.0138 Fixed Magnification C $450.00
  WH027-220A-120 8(1/2") 0.270 220 0.0163 Fixed Magnification C $386.00
  WH03-130A-120 8(1/2") 0.300 130 0.0133 Fixed Magnification C $386.00
  WH03-180A-120 8(1/2") 0.300 180 0.0133 Fixed Magnification C $386.00
  WH03-240A-120 8(1/2") 0.300 240 0.0167 Fixed Magnification C $386.00
  WH03-530-123 8(1/2") 0.300 530 0.0188 Fixed Magnification C $471.00
  WH05-300CT 8(1/2") 0.500 300 0.0100 Fixed Magnification C $557.00
  WH05-330CIR 8(1/2") 0.500 330 0.0210 Fixed Magnification C $557.00
  WH10-250CS-120 8(1/2") 1.000 250 0.0250 Fixed Magnification C $386.00
  WH20-300A-120 8(1/2") 2.000 300 0.0333 Fixed Magnification C $494.00

9 items
